Heavy Duty Pipe Welding Rotator, 100T Bolt Adjustment Welding Tank Roller Stands

Ask Lasest Price
Brand Name :	Weldsuccess
Model Number :	HGK - 100
Certification :	ISO / CE / CO
Price :	Negotiation
Payment Terms :	T/T, L/C, D/P
Supply Ability :	5 Sets Per Month
Delivery Time :	10 Days

Add to Cart

Product Details
Company Profile

Heavy Duty Pipe Welding Rotator, 100T Bolt Adjustment Welding Tank Roller Stands

Heavy Duty Pipe Welding Rotator, 100T Bolt Adjustment Welding Tank Roller Stands
WELDSUCCESS PRODUCTS.pdf

Bolt Adjustment Pipe Welding Rotator Brief Description:

1. Our welding rollers pack One drive piece roller & one idler piece roller together as one set for sale.

2. Remote hand control, Radio hand control & Foot pedal control are all avaialble.

3. Top-class electronic components from Schneider to ensure long time using life.

4. Our tank tuning rolls' drive rotation speed is in digital readout.

5. Voltage : 110V - 600 V 50 / 60 Hz 1P / 3P all available

6. If your single pipe length more than 8 meter, we suggest you choose one drive roller and two idler rollers to support.

Here Below is 100Tons Pipeline Welding Rotator Specification:

Model	HGK-100
Load capacity - Set	100 tons maximum
Rotation capacity	100 tons maximum
Vessels diameter	Min. 800mm ~ Max.5000mm
Rotation speed	100~1000 mm/min VFD
Rotation power	2*3kw with fan cooling
Roller wheels	PU (Polyurethane wheels)
Control way	Remote hand control + Foot pedal
Input Voltage	110V ~ 575V Single/3 Phase 50/60Hz
Certificate	CE approval

Why Choose Our Automatic Welding Rotator And Other Welding Machine

1. We are welding equipment MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.

2. We have strong design & technical team, we can design and manufacture as per the customer's requirement.

3. Our main products (Includes Welding Manipulator, Welding Rotator, Welding Positioner, Longitudinal Seam Welding Machine, Edge Milling Machine) have been approved CE certificate.

4. We have successfully exported to Europe, USA, Middle East, Southeast Asia and so on more than 30 foreign countries.

5. We provide a FREE ONE YEAR WARRANTY for all our items.

Tank Turning Rolls Stands / Pipe Welding Rotator Spare Parts Brand:

Our welding roller Inverter is from Danfoss / Yaskawa
Our welding rotator Motor is from Invertek
Our Tank rolls Reducer is from China brand
Our welding Electric system is from Schneider

Application:

Used to weld, polish and assemble the cylinder-shells, and to line the shells with rubber. Welding Rotator major used in cylinder welding ,such as Marine,Oil&Gas ; Offshore,Petro Chemical ; Plate Heat Exchanger ; Charged air cooler ; Pressure Vessel ; Boiler ; Pipe system&Steel works etc.

That automatic welding machine including: manipulator, welding rotator, and electric system etc, mainly used to weld the butt welding seam which formed from the pipe, pipe elbow, pipe flange, perpendicular tee pipe. The welding head will be relatively fixed, while the piping spool piece revolving at a specific rate, and the high efficient and low cost shielded welding or SAW process is adopted, so it has the features of easy-operation, reliable-performance and wide-application field,and which enhancing productivity, increasing the extent of automatic, reducing welder’s working intensity and adapting to piping workshop prefabrication.

DO NOT HESITATE ! JUST SEND US YOUR INQUIRY NOW.
