Product Description:
1.Our pipe welding rotators pack One drive piece roller & one idler
piece roller together as one set for sale.
2.Our tank tuning rolls' drive rotation speed is in digital
readout.
3.Top-class electronic components from Schneider to ensure long
time using life
4.Remote hand control, Radio hand control & Foot pedal control are
all avaialble.
5.100% new from original manufacturer
6. If your single pipe length more than 8 meter, we suggest you
choose one drive roller and two idler rollers to support.
Features:
1.The pipe welding rollers product has following different
series,say, the self-alignment, the adjustable, the vehicle, the
tilting and the anti-drift types.
2.The series conventional pipe welding rollers stand is able to
adopt to various diameter of job, by adjust the center distance of
rollers, via reserved screw holes or lead screw.
3.Depends on different application, the roller surface has three
types,PU/RUBBER/STEEL WHEEL.
4.The pipe welding rollers is mainly used for Pipe Welding ,tank
rolls polishing,turning roller painting and tank turning rolls
assembly of cylindrical roller shell.
5.The pipe welding turning roller machine can joint control with
other equipments.
Technical Parameters:
| Model | CR-80 |
|---|
Turning Capacity | 80 Ton Maximum |
Drive Load Capacity | 40 Ton Maximum |
Idler Load Capacity | 40 Ton Maximum |
Adjust Way | Bolt Adjustment |
Motor Power | 2*3KW |
Vessel Diameter | 500-5000mm |
Rotation Speed | 100-1000mm/min |
Speed control | Variable frequency driver |
Roller wheels | PU |
Roller size | Ø500*360mm |
Voltage | 380v±10% 50Hz 3Phase |
Control system | Foot pedal 15m cable |
Color | Customized |
| Warranty | 1 Year |
Applications:
1. Pressure vessel;
2. Pipe manufacturing industries
3. Wind power fabrication
4. Chemical & fuel storage tank fabrication
5. Any heavy cylindrical job
1. We provide 12month guaranty period for the whole machine
quality.
2. During this time, any issue proved because of the machine flaw
itself,we would take the whole responsibility of it.
3. Except of the guaranty period,technical advisory support is
available freely covering the whole using life of the machine.
4. Engineer service on user premises is also available for
necessary.
Packing and Shipping:
1. Seaway is the most common transportation way for oversea
trading.
2. Depends on your location, combined transport by rail and sea is
also an option.
3. Certainly railway transportation is also acceptable if it is the
most suitable approach.
4.All package in wooden case for delivery to avoid damage.
5.It will be placed in an anti-rust coating for extra protection
and then covered with a thick foam sheet.
6.The crate will be sealed with screws and nails to ensure that it
is secure and will not be damaged in transit.
7.Once it is shipped, it will be tracked with a tracking code to
ensure that it is delivered safely and on time.
8. All boxes are labeled with the product name and number, and the
shipper's contact information.
FAQ:
- Q: What is the brand name for the Pipe Welding Rotator?
A: The brand name for the Pipe Welding Rotator is Weldsuccess.
- Q: Where is the Pipe Welding Rotator manufactured?
A: The Pipe Welding Rotator is manufactured in China.
- Q: What certifications does the Pipe Welding Rotator have?
A: The Pipe Welding Rotator has ISO/CE/CO certification.
- Q: What is the minimum order quantity for the Pipe Welding Rotator?
A: The minimum order quantity for the Pipe Welding Rotator is 1
set.
- Q: How is the Pipe Welding Rotator packaged?
A: The Pipe Welding Rotator is packaged in a wooden case.
