    Self Aliging Welding Rotator

    Ask Lasest Price
    Brand Name : SKSS
    Model Number : HGZ - 40
    Certification : ISO / CE / CO
    Price : Negotiation
    Payment Terms : T/T, L/C, D/P
    Supply Ability : 5 Sets Per Month
    Delivery Time : 10 Days
    • Product Details
    • Company Profile

    Self Aliging Welding Rotator


    Self Aliging Welding Rotator

    Description


    1. Consist : One powered roller , One idler roller , Electric control system

    2. Adjust way : Adjust the pipe diameter automatically with diameter 600 - 4200 mm

    3. Voltage : 110V - 600 V 50 / 60 Hz 1P / 3P all available

    4. Control Way : Remote hand control box / Wireless hand control box

    5. Roller Material : Rubber / Steel / PU ( Polyurethane roller for Nonferrous Metals )

    6. Original : Our factory / Wuxi China


    Others


    1. All our pipe welding rotators have 20% over weight design, but we suggest used on the safety rangs.

    2. We have strong delivery team, including the Sea freight and Air transportation. Door to door available.

    3. Just advise me your desitination port then we will give you the final CIF price.

    Specification


    Model

    HGZ-5

    HGZ-10

    HGZ-20

    HGZ-30

    HGZ-40

    Max Capacity

    5 T

    10 T

    20 T

    30 T

    40 T

    Roller Diameter (mm)

    250

    300

    350

    350

    400

    Roller Width (mm)

    100

    120

    Working Range (mm)

    250-2300

    320-2800

    500-3500

    530-3700

    600-4200

    Roller Speed (m/h)

    6-60

    Motor Power (kw)

    0.75

    1.1

    1.5

    2.2

    3

    Option :

    □ Moving wheels □ Wireless Control □ Remote Control


    Applications


    1. Support the pipe for turning and welding.

    2. Adjust the pipe butt position for auto circle seam welding.

    3. We also have the moving model available.


    Self Aliging Welding Rotator


    Control system and Brand


    1. Inverter is from Taida / Yaskawa Brand

    2. Motor is from UK Invertek Brand

    3. Reducer is from Cable. Made in China.

    4. Electric system is from Schneider / Siemens


    More Questions Customers May Concerned


    Q : What about the transportion?


    A : 1. Fully packaged in wooden case to anti damage during the transportational process .

    2. Usually we take seaway ,cause its more convenient and cheaper for big machine.

    3. Door to door delivery service is also available.


    Q : What is your warranty and after sale service ?


    A : 1. All our equipments with One Year Warranty time , fully test at our work shop before delivery.

    2. If you have any questions on the installation , you will get our engineers respond within 24 hours.


    Q : Do you have overseas agent available ?


    A : Yes. We have some distributors from European , Amercia , South-East Asia etc. Via OEM service.


    Self Aliging Welding Rotator


    Attention please


    1. Normally under 60 T model we use the Rubber material rollers , upper we use Steel material rollers.
    2. If your work piece material is Nonferrous Metals , we suggest PU rollers.
    3. Self-aligning welding rotator / Bolt adjsutment / Lead Screw adjustment / Fit up rotators all available.
    4. If your single pipe length more then 8M , then you should use 1 powered with 2 idlers to support.
