    Wireless Control Welding Pipe Stands with Rollers, Self Adjustment 80T Heavy Duty Pipe Stands

    Ask Lasest Price
    Brand Name : Weldsuccess
    Model Number : HGZ - 80
    Certification : ISO / CE / CO
    Price : Negotiation
    Payment Terms : 30% Payment in advance via T/T, L/C, D/P
    Supply Ability : 5 Sets Per Month
    Delivery Time : 20 Days
    • Product Details
    • Company Profile

    Wireless Control Welding Pipe Stands with Rollers, Self Adjustment 80T Heavy Duty Pipe Stands

    Self Adjustment 80T Heavy Duty Pipe Welding Rotator Stands , Wireless Control Welding Pipe Stands with Rollers More products pics.pdf


    Supply Ranges


    1. Pipe Welding Rotator consist : One powered roller , One idler roller , Electric control system

    2. Adjust way : Adjust the pipe diameter automatically with diameter 33 - 200 inches

    3. Pipe Welding Rotator voltage : 110V - 600 V 50 / 60 Hz 1P / 3P all available

    4. Control Way : Remote hand control box / Wireless hand control box

    5. Roller Material : Rubber / Steel / PU ( Polyurethane roller for Nonferrous Metals )

    6. Original : Our factory / Wuxi China


    Pipe Welding Rotator Specification


    Model

    HGZ-60

    HGZ-80

    HGZ-100

    HGZ-150

    HGZ-200

    Max Capacity

    60 T

    80 T

    100 T

    150 T

    200 T

    Roller Diameter (mm)

    450

    500

    550

    550

    550

    Roller Width (mm)

    120

    Working Range (mm)

    750-4800

    850-5000

    1000-5500

    1200-6500

    1500-8000

    Roller Speed (m/h)

    1 - 1000 mm/min

    Motor Power (kw)

    4

    4

    5.5

    5.5

    7.5

    Option :

    □ Moving wheels □ Wireless Control □ Remote Control


    Pipe Welding Rotator Applications


    1. If you want moving function , just send us one email.

    2. For big tank seam welding after plate rolling.

    3. For single tanks butt welding to be the big one pipe.


    More Questions Customers May Concerned


    Q : What about the transportion?

    A : 1. Fully packaged in wooden case to anti damage during the transportational process .

    2. Usually we take seaway ,cause its more convenient and cheaper for big machine.

    3. Door to door delivery service is also available.


    Q : What is your warranty and after sale service ?

    A : 1. All our pipe welding rotator with One Year Warranty time , fully test at our work shop before delivery.

    2. If you have any questions on the installation , you will get our engineers respond within 24 hours.


    Pipe Welding Rotator Details Control system and Brand


    1. Inverter is from Taida / Yaskawa Brand

    2. Motor is from CE Invertek Brand

    3. Reducer is from Cable. Made in China.

    4. Electric system is from Schneider


    Our suggestion


    1. Normally under 60 T model we use the Rubber material rollers , upper we use Steel material rollers.
    2. If your work piece material is Nonferrous Metals , we suggest PU rollers.
    3. Self-aligning pipe welding rotator / Bolt adjsutment / Lead Screw adjustment / Fit up rotators all available.

    4. Write us for DOOR TO DOOR price.


    DO NOT HESITATE ! JUST SEND US YOUR INQUIRY NOW.
