| Ask Lasest Price | |
| Brand Name : | Weldsuccess |
| Model Number : | LHC 5050 |
| Certification : | ISO / CE / CO |
| Price : | Negotiation |
| Payment Terms : | T/T, L/C, D/P, D/A |
| Supply Ability : | 3 Sets Per Month |
| Delivery Time : | 25 Days |
5000 mm Diameter Welding Column And Boom , Pressure Vessels Seam Welding Automatic Pipe Welder
Welding Column And Boom Description
1. Other Name : Welding Column And Boom Manipulator
2. Condition : 100% brand new
3. Place of origin : Wuxi China(Mainland)
4. Model number : Light Duty / Middle Duty / Heavy Duty
5. Usage : Welding / Pressure Vessel , Boiler , Tanks seam welding
6. Voltage : 110V-600V , Please advise me yours when you send us the inquiry.
7. Out seam welding , Inner seam welding , circle seam welding . SAW / TIG etc..
Welding Column And Boom Manipuator Using Specifications
Model | LHC-4040 | LHC-5050 | LHC-6060 | LHC-8080 |
Effective Vertical Lifting Stroke of Boom (mm) | 4000 | 5000 | 6000 | 8000 |
Effective Horizontal Retracting Stroke of Boom (mm) | 4000 | 5000 | 6000 | 8000 |
Boom Lifting speed (mm/min) | 1 | |||
Boom Retracting speed (mm/min) | 0.12-1.2 | |||
Column Rotation Angle (°) | □ Stationary □ ±180° | |||
Column Rotation Way (rpm) | □ Stationary □ Manual □ Motorized(0.1) | |||
Trolley Traveling Way (mm/min) | □ Stationary □ Manual □ Motorized(1.5/3) | |||
Option : | □ Seam Tracker □ Flux recovery machine | |||
Welding Source □ Chinese □ Lincoln Brand | ||||
Welding Column And Boom Applications
1. To weld the inner seam and outside seam automatically.
2. Auto Flux recovery machine / seam teacker / monitor are all available.
Welding Column And Boom Advantages
1. ±180° degree column rotation with manual locking at any position
2. Motorized cross slider 100*100mm fine adjustment stroke to
welding gun
3. It can realize automatic welding incorporate with SAW, MAG and
TIG welding systems
4. Extensively applied in pressure vessel , power , chemical
industry , wind tower and others lines
5. Variable speed boom controlled by inverter
More Details Of Welding Column And Boom
1. There is safe ladder behind the column for maintenance of
equipment
2. Limit switch for both boom travel and lift
3. All motion parts have lubrication system
4. Main electric elements are ABB / Siemens brands
5. Sand blasting treatment to main welding parts before painting
6. ISO9000 & CE certification supported
