Moving Rotation Welding Column and Boom Manipulator , Vessels Seam Arc Welding Equipment
Here Below Is Welding Manipulator Description
1. Auxiliary equipment for welding center.
2. Automatic welding manipulator can be selected various welding power.
3. Stretching of cross boom adapts AC frequency converter stepless.
4. Head equipped with electric cross slides, can adjust position of welding.
5. Chain break-resistant and anti-slip device in boom to guarantee safety.
6. Braking device can ensure column work in safe environment.
7. Automatic flux feeding, recovering devices, wire feeder device, working platform and chair.
8. Customized requirements are accepted.
Here Below is Welding Manipulators Specifications
Model | LHC-3030 | LHC-3040 | LHC-4050 | LHC-5060 |
Effective Vertical Lifting Stroke of Boom (mm) | 3000 | 3000 | 4000 | 5000 |
Effective Horizontal Retracting Stroke of Boom (mm) | 3000 | 4000 | 5000 | 6000 |
Boom Lifting speed (mm/min) | 1 | |||
Boom Retracting speed (mm/min) | 0.12-1.2 | |||
Column Rotation Angle (°) | □ Stationary □ ±180° | |||
Column Rotation Way (rpm) | □ Stationary □ Manual □ Motorized(0.1) | |||
Trolley Traveling Way (mm/min) | □ Stationary □ Manual □ Motorized(1.5/3) | |||
Option : | □ Seam Tracker □ Flux recovery machine | |||
Welding Source □ Chinese □ Lincoln Brand | ||||
Welding Manipulator Productive Process
1. Cross-tuning system with motorized slide can realize welding torch in three-dimensional adjust,which satisfy welding torch adjust for welding longitudinal and circle seam,200mm adjust range can make the easy operation.
2. Control roller has eccentric shaft, which can decrease clearance between roller and rail.
3. Column boom welding manipulator adopts a total-sealing oil immersion lubricating mode to help keep off dust, slag, and many other impurities.
4. Control box includes control box and pendant ,interface with positioner and rotator also prepared.
After-sales Service For Welding Manipulator
1. Our products welding manipulator is for one year warranty and
life long maintenance.
2. A large stock of components and parts, easily-worn parts.
3. If customer need installation and commissioning,we’ll send 3 workers to customer’s factory ,including one machinery worker,one electrician and one translator.But customer should pay the cost of installation and commissioning.
FAQ
Q: Can your machine or other products be customized?
A: Yes,we are an professional manufacturer who specializes in welding equipment about 15 years old,
we have a strong design team ,so any conventional products can be customized.
Q: What about the transportion?
A: Usually we take seaway ,cause its more convenient and cheaper for big machine,of course ,
if it is allowed ,we also can take train ,its according to real condition.
Q: What about the after-sale service?
A: We provide 12 months quality warranty after dispatch, and some easy abrasion spares of equipment
for free. We also provide a long term free technical advisory services and technical consults service.
We can also provide installation and training for value.
When you send us the inquiry, please advise us your single tank diameter and length.
|
