3T Capacity Hydraulic Tilting And Rotation Pipe Welding Positioners With Hand Control Foot Pedal WELDSUCCESS PRODUCTS.pdf
Pipe Welding Positioners Description:
1. Voltage : 220V - 600V 50 / 60 Hz all available.
2. Tilting angle : 0 - 90 ° / 0 - 120 ° available.
3. Hydrulic Lifting System 800 mm lifting stroke
4. Original : Wuxi China - Wuxi Success Machinery Equipment Co., Ltd
5. Package : Wooden case / Electric Control System
Here Below is 3T Hydraulic Pipe Welding Positioners Spacification
| Model | YHB-30 |
| Load capacity | 3000kg maximum |
| Table diameter | 1400mm |
| Tilting angle | 0-120° |
| Tilting speed | 0.2 rpm |
| Tilting power | 2.2 kw |
| Rotation speed | 0.05-0.5 rpm |
| Rotation power | 1.5 kw |
| Control way | Remote hand control + Foot pedal |
| Input Voltage | 110V ~ 575V Single/3 Phase 50/60Hz |
| Certificate | CE approval |
Hydraulic Pipe Welding Positioners Application
1. Lift type pipe welding positioners machine is mainly used to place the workpiece in the best position for
welding and assembling with the worktable elevating, rotation, tilting.
2. It can be used for various automatic or manual welding, butt welding or face welding of pipe, as well as welding of shafts, discs, barrel, etc, with advantages of compact volume, good appearance,
light weight and easy operationThe positioner can be supplied for interfacing with robot or welding manipulators, to realize the welding automation.
5. All CE certificates supported brand
Pipe Welding Positioners Competitive Advantage
1. It’s easy to control with electric cabinet and hand control panel.
2. Slewing bearing will ensure turning and over turning smoothly.
3. Several concentric grooves are processed onto the surface of the worktable to help position the work
piece at the center.
Clamps for reference
1. We have 3 jaws or 4 jaws chucks for chosen, and pipe diameter from 50 mm to 1200 mm.
2. Special clamps are available,but we have to design according to your work piece detail drawings.
3. Special tilting platform is available.
Delivery and after sale service
1. One / Two sets pipe welding positioners we will package in wooden case.
2. If order quantity is enough for one container, we will package in container directly.
3. We have engineers supply you the door to door installation service.
4. All the installation drawings and work manual document will send to you via Email.
5. We are the factory, so we can supply you all the technology problems helps.
JUST SEND EMAIL FOR MORE DETAILS NOW.
|
|
